| Material |
Plunger/barrel: Brass Spring: Stainless steel |
| Electroplating |
Plunger: Gold plating 0.4um over nickel 1.4um Barrel: Gold plating 0.1um over nickel 1.4um |
| Electrical specification |
Contact electrical resistor: 30mOhm Max. Rated voltage: 36V DC Max Rated current: 2.0A |
| Mechanical performance | Life: 10,000 cycle min. |
Intelligent wearable devices: Smart watches, smart wristbands, locator devices, Bluetooth headphones, smart shoes, smart glasses, smart backpacks, etc.
Smart home: Smart appliances, air purifiers, automatic controllers, etc.
Industrial & Medical: Medical equipment, wireless charging equipment, data communication equipment, telecommunications equipment, automation and industrial equipment, etc.
3C Consumer electronics: Laptops, tablets, PDAs, handheld data terminals, etc.
Aviation & Vehicles: Aviation, aerospace, military communication, military electronics, automobiles, vehicle navigation, testing fixtures, testing equipment, etc.
The plunger and barrel are constructed from premium brass, while the internal spring is made of stainless steel to ensure consistent force and longevity.
To guarantee optimal electrical conductivity and prevent oxidation, the plunger is plated with 0.4um gold over 1.4um nickel, and the barrel features 0.1um gold over 1.4um nickel.
These spring-loaded connectors support a maximum rated current of 2.0A and a maximum rated voltage of 36V DC, with a maximum contact resistance of 30mOhm.
The pogo pins are designed for durability, offering a minimum mechanical lifespan of 10,000 mating cycles.
Yes, they are highly optimized for space-constrained applications like smart watches, smart wristbands, Bluetooth headphones, medical equipment, and automotive testing systems.
